The Verbex VTS-WD6S 6-Zone Walk-Through Metal Detector Gate is a professional-grade full-body security scanner designed to detect concealed metal objects with precision and speed. Built for high-traffic areas like airports, offices, events, schools, and government buildings, this archway detector combines infrared sensing, multi-zone accuracy, and waterproof construction for both indoor and outdoor use. With adjustable sensitivity, sound & light alarms, and LCD display, it ensures reliable and efficient security screening for any environment.
Full Specifications
| General Information | |
|---|---|
| Brand | Verbex |
| Model | VTS-WD6S |
| Product Type | Full Body Walk-Through Metal Detector Gate |
| Detection Zones | 6 Independent Zones |
| Display Type | Super Bright LCD Display |
| Alarm Type | Sound & Light Indicator |
| Material | PVC Synthetic Material (Waterproof) |
| Warranty | 1 Year (with On-Site Service) |
| Technical Specifications | |
| Power Supply | AC 90V–250V, 50/60Hz |
| Power Consumption | Less than 20W |
| Sensitivity Levels | 0–200 Adjustable |
| Working Temperature | -20°C to +50°C |
| Certificates | CE, FCC, RoHS |
| Built-in Battery Backup | Yes (2–8 hours continuous use) |
| Counting Function | Automatic traffic & alarm counting |
| Password Protection | Yes, double password protection |
| False Alarm Prevention | Digital, analog, left/right balance technology |
| Electromagnetic Safety | EMC standard – safe for pacemakers & pregnant women |
| Physical Dimensions | |
| Outer Frame | 2210 mm (H) × 810 mm (W) × 480 mm (D) |
| Inner Frame | 2000 mm (H) × 700 mm (W) × 480 mm (D) |
| Weight | 55 kg |
| Performance | |
| Detection Range | Full Body (6 Zone Identification) |
| Alarm Indication | Audio & Visual LED Zone Indicators |
| Outdoor Usage | Yes (Waterproof & Weatherproof) |
| Installation Time | Approximately 20 minutes |
| Application Areas | Airports, Events, Schools, Offices, Malls, Government Buildings |
| Origin & Assembly | |
| Country of Origin | UAE (Dubai) |
| Assembled In | China |
Description
The Verbex VTS-WD6S Walk-Through Metal Detector Gate features 6 high-precision detection zones, allowing security personnel to pinpoint the exact area of a detected metal object head, torso, legs, or sides. This ensures faster screening, fewer false positives, and minimal disruption at busy checkpoints.
Powered by digital signal processing technology, the system uses infrared sensors to detect even small metallic items while minimizing interference from external electronic devices. Adjustable sensitivity levels (0–200) allow you to tailor the performance for different environments from schools and event halls to high-security airports.
When metal is detected, the LED zone indicators light up, and an audible alarm sounds to guide personnel to the exact location of the metal. The super-bright LCD display provides clear visibility for operation, configuration, and counting data even in low-light environments.
The VTS-WD6S is fully waterproof and built with high-grade PVC synthetic material, ensuring reliable performance in rain or extreme weather conditions. Its luxurious, corrosion-resistant finish makes it ideal for both permanent installations and mobile event setups.
With built-in power support, the detector can continue operating for 2–8 hours during power outages. The low power consumption (<20W) ensures energy efficiency while maintaining optimal performance.
Designed with EMC radiation standards, the Verbex VTS-WD6S uses weak magnetic fields that are safe for all users — including those with pacemakers, pregnant women, and medical devices. Its password-protected interface prevents unauthorized settings changes, while its auto memory system retains configurations even without power.
The integrated modular design allows setup or dismantling within 20 minutes. Each unit includes a detailed installation and operation manual, ensuring fast deployment and ease of use for security teams.
The Verbex VTS-WD6S is ideal for:
The Verbex VTS-WD6S 6-Zone Walk-Through Metal Detector Gate is a premium-grade, multi-functional security scanner that combines precision detection, durability, and smart technology. Whether used indoors or outdoors, it ensures fast, accurate, and safe screening for every individual - delivering peace of mind and reliability in every setting.
The latest price of the Full Body Walk through Security Scanner Archway Metal Detector Gate 6-Zones - Verbex VTS-WD6S in Bangladesh is 65,000 BDT. You can buy the Full Body Walk through Security Scanner Archway Metal Detector Gate 6-Zones - Verbex VTS-WD6S at the best price from our website.
1. How many detection zones does this model have?
It features 6 detection zones, each capable of pinpointing the metal object’s exact location.
2. Can it be used outdoors?
Yes, it is waterproof and weather-resistant, ideal for both indoor and outdoor security setups.
3. Does it work during power outages?
Yes, it includes a built-in battery backup that allows operation for 2–8 hours without main power.
4. Is it safe for people with pacemakers?
Absolutely. It uses low-intensity magnetic fields compliant with EMC standards, making it completely safe.
5. How long does installation take?
The modular design allows for installation or removal within 20 minutes.
6. What is the warranty period?
The Verbex VTS-WD6S comes with a 1-year warranty, including on-site service.
